Clamp-on Ultrasonic Flow Meter

  • Introduction
  • Picture
  • Specification
  • Download
  • Installation Video
  • Inquiry



Name:Clamp-on Ultrasonic Flow Meter
Model:LRF-3300SW
Size:254*230*64mm



General Introduction:
LRF-3300S is a wall-mount, clamp- on type ultrasonic flowmeter which use the transfer time technology. Clamp on type ultrasonic flowmeter is easy to install and no need to cut off the pipe, that saves you lots of troubles and cost. At the same time
LRF-3300S has our unique calculate software to ensure the high accuracy and low velocity response. LRF-3300S could add the RTD model and temperature sensor become an energy meter to monitoring the energy use, help to save the energy.


Selection of parameter:
Model Transmitter
LRF-3300S Ultrasonic flowmeter
Wall mount
Flow range :±0.01m/s ~ ±12m/s
Accuracy :±0.5% of the measure value
Repeatability:0.1% of the measure value
Display:240*128 backlit LCD
Power supply:90-250VAC,48-63Hz or 10-36VDC
Output:4-20Ma,OCT,Relay
Communication :RS232/RS485,Modbus
Code Output
1 OCT,Relay,RS232/485,4-20mA
2 OCT,Relay,RS232/485,4-20mA,RTD
Code Transducer
TT02 Clamp-on, IP68,Operating temperature: -40℉ ~ + 176℉(-40℃ ~ +80℃)(Standard)
TT03 Clamp-on, IP68,Operating temperature: 32℉ ~ + 266℉(0℃ ~ +130℃)(High Temp)
XXX Transducer cable length
030 Standard length 30ft (9m)
XXX Max length to 1000ft (300m)
Code Temperature sensor
PT1000 PT1000 temperature sensor


Transmitter:
Clamp-on Ultrasonic Flow Meter

Transducer:
Clamp-on Ultrasonic Flow  Meter
size:
Clamp-on Ultrasonic  Flow Meter
weight:
Clamp-on  Ultrasonic  Flow Meter
Installation diagram:
Clamp-on  Ultrasonic  Flow  Meter

Performance
Flow range ±0.09ft/s ~ ±40ft/s (±0.03m/s ~ ±12m/s)
Accuracy ±0.5% of reading (for ±1.5ft/s~±40ft/s)
Repeatability 0.1% of measured value
Pipe size 1"to 200" (25mm to 5000mm). Pipe size under 1" is an option
Linearity ±0.5%
Function
Outputs Analog output: 4~20mA, max load 750 Ω.
Pulse output: 0~9999Hz, OCT, (min. and max. frequency is
adjustable)
Relay output: SPST, max 1Hz,(1A@125VAC or 2A@30VDC)
Communication RS232 & RS485
Memory TF card (Max 32G)
Power supply 90 to 245 VAC, 48 to 63 Hz. Or 10 to 36VDC
Display 240*128 back lit LCD
Temperature Transmitter: -40℉~ 140℉(- 40℃ ~ 60℃ ).
Transducer:  -40℉~ 176 ℉(- 40 ℃ ~ 80 ℃(Standard)
Transducer:  32℉~ 356 ℉( -0 ℃ ~ 180 ℃(High Temp type))
Humidity  Up to 99% RH,non-condensing
physical
Transmitter  IP65
Transducer IP68
Encapsulated design
Double-shielded transducer cable
Standard/maximum cable length:30ft/1000ft(9m/300m)
